24-bit/48 kHz Digital Wireless System: The system offers 24-bit/48 kHz digital wireless transmission, ensuring superior sound quality and reliable audio performance, essential for professional applications.

2.4 GHz Frequency Range: By operating in the 2.4 GHz frequency range, the ATW-1701X3M avoids interference from DTV and 4G signals, maintaining consistent audio quality even in crowded environments.

Automatic Frequency Selection: The automatic frequency selection feature simplifies the setup process, making it easy to get started without complicated configurations. This plug-and-play function ensures reliable operation right from the start.

Three Levels of Diversity (Frequency, Time, Space): To prevent signal interference, the system uses three levels of diversity—frequency, time, and space. This combination significantly reduces dropouts and ensures clear communication throughout use.

Compact, Portable Receiver: The ultra-compact and lightweight receiver allows for versatile mounting options, making it suitable for various camera setups and recording devices. The receiver also includes a user-friendly interface with channel selection and instant setup capabilities.

Balanced and Unbalanced Output Jacks: With both balanced and unbalanced output jacks, the system offers selectable level control, ensuring compatibility with a wide range of cameras and recording devices.

12-Hour Battery Life: An internal rechargeable battery provides up to 12 hours of continuous operation, ensuring long-lasting performance for extended recording sessions.

Independent Headphone Jack and Volume Control: The system includes a headphone jack with independent volume control, allowing real-time local audio monitoring for precise sound management.

Included Cardioid Condenser Lavalier Microphone: The package comes with a high-quality cardioid condenser lavalier microphone, offering clear audio capture for professional-grade sound recordings.

Specifications:

• Operating Frequencies: 2.4 GHz ISM band
• Frequency Response: 20 Hz to 20 kHz
• Operating Range: 30 m (100′) radius, 60 m (200′) diameter
• Dynamic Range: >109 dB (A-weighted)
• Total Harmonic Distortion: <0.05%
• Battery Type: Internal rechargeable Li-ion
• Battery Life: 12 hours
• Dimensions (Receiver): 56.0 mm (W) x 91.4 mm (H) x 27.8 mm (D)
• Weight (Receiver): 105g

Belt Pack

• RF Power Output: 10 mW
• Input Connections: Four-pin locking connector
• Battery Life: >7 hours (alkaline)
• Dimensions: 70.2 mm (W) x 107.0 mm (H) x 24.9 mm (D)
• Weight: 100g without batteries
