Powerful Sound Performance: The LINEAR 5 MK2 112XA delivers exceptional audio with its 12″ low/mid speaker and 1″ HF driver. It achieves a peak SPL of 136 dB, providing clear sound even at high volumes. With a frequency response from 67 Hz to 19 kHz, it offers full-spectrum audio for a variety of professional applications.

Class D Amplification: This speaker is powered by a Class D bi-amped amplifier, delivering 600 watts RMS and 1,200 watts peak power. The efficient design ensures high output while minimizing energy consumption. The bi-amped system optimizes performance for both low and high frequencies, ensuring dynamic and clear sound reproduction.

Rotatable Horn for Optimal Sound Dispersion: The speaker features an 80° x 60° rotatable CD horn. This allows for flexible sound dispersion in narrow spaces or clustered setups. It ensures sound reaches the intended areas, improving clarity and coverage in any environment.

DSP Control Software: The DSP Control software lets users remotely control the speaker’s settings, including a 10-band parametric EQ and high-pass/low-pass filters. This software enables precise tuning for optimal performance, making it ideal for various performance environments.

Cardioid Subwoofer Setup: The LINEAR 5 MK2 112XA supports a cardioid subwoofer setup that minimizes unwanted bass dispersion behind the stage. This results in a cleaner sound for the audience while reducing interference, making it perfect for live performances.

Lightweight and Durable Design: Despite its powerful output, the speaker weighs only 17.6 kg (38.8 lbs), making it easy to transport. Its hybrid construction combines birch multiplex and MDF for durability, while the black acrylic enamel finish ensures a sleek, professional look.

Flexible Mounting and Rigging: The speaker’s DuoTilt pole mount system offers 3° or 7° tilt options, allowing for flexible positioning. It also includes rigging points for easy setup in both portable and permanent installations.

Specifications:

• Max SPL @ 10% THD: 128 dB
• Frequency Response: 67 Hz – 19 kHz
• Power Output (RMS/Peak): 600 W / 1,200 W
• Amplifier Type: Class D, bi-amped
• Horn Angle: 80° x 60°
• DSP Control: Yes, with software support
• Weight: 17.6 kg
• Dimensions: 36 x 59 x 30.5 cm
• Mains Connection: IEC connector, 100-240 V
• Rigging Points: 3x M8
