Special Elliptical Stylus: The Special Elliptical stylus provides accurate groove contact and supports precise sound reproduction during vinyl playback.

Strengthened Cantilever: The extra-strengthened cantilever provides rigidity for demanding DJ techniques, including scratching and back-cueing.

Balanced Performance: Ortofon developed the cantilever for balanced movement, supporting stable tracking throughout demanding DJ sessions.

Excellent Tracking: The stylus provides reliable tracking ability, helping maintain accurate groove handling during active vinyl performance.

Reduced Record Wear: Its low-wear design helps minimise record wear, making it suitable for frequent DJ use.

Flexible Tracking Force: The Stylus DJ E supports a 2.0–4.0 g tracking force range, with 3.0 g recommended.

Reliable DJ Performance: The DJ series combines tracking performance, durability, and accurate sound reproduction for versatile vinyl applications.

Specifications:

• Brand: Ortofon
• Product: Stylus DJ E
• Application: Replacement stylus
• Stylus Type: Special Elliptical
• Stylus Tip Radius: r/R 13/25 μm
• Channel Balance at 1 kHz: 2 dB
• Channel Separation at 1 kHz: 23 dB
• Tracking Ability at 315 Hz: 80 μm
• Compliance, Dynamic, Lateral: 9 μm/m N
• Tracking Force Range: 2.0–4.0 g (20–40 mN)
• Recommended Tracking Force: 3.0 g (30 mN)
• Tracking Angle: 20°
• Internal Impedance, DC Resistance: 750 Ohm
• Cartridge Weight: Stylus = 1 g
• Recommended Load Resistance: 47 kOhm
• Internal Inductance: 450 mH
• Recommended Load Capacitance: 200–600 pF
• Designed For: Scratch and back-cueing
• Compatible Cartridge Family: Concorde MKI & OM
