Spherical Diamond: The spherical diamond supports reliable groove contact while DJs scratch, mix, and perform demanding vinyl techniques.

Secure Groove Tracking: The stylus stays firmly within the groove during scratching and back-cueing for dependable performance.

Designed for Scratching: Its construction supports DJs who regularly use scratching techniques during active vinyl performances.

Mixing Performance: The Night Club S also suits mixing applications, providing consistent tracking across extended DJ sessions.

Extended Performance: The secure groove handling supports reliable operation during lengthy nightclub and performance environments.

Strong Output: The stylus provides a 6 mV output voltage at 1 kHz and 5 cm/sec for strong signal delivery.

Balanced Stereo Reproduction: With 1.5 dB channel balance and 23 dB channel separation, the stylus supports consistent stereo playback.

Specifications:

• Brand: Ortofon
• Product: Stylus Night Club S
• Application: Replacement stylus
• Compatible Cartridge: Concorde & OM Nightclub cartridge
• Channel Balance at 1 kHz: 1.5 dB
• Output Voltage at 1 kHz, 5 cm/sec: 6 mV
• Channel Separation at 1 kHz: 23 dB
• Frequency Response: 20 Hz–20 kHz, +3/-2 dB
• Tracking Ability at 315 Hz: 80 μm
• Compliance, Dynamic, Lateral: 7 μm/m N
• Stylus Type: Spherical
• Stylus Tip Radius: R 18 μm
• Tracking Force Range: 2.0–5.0 g (20–50 mN)
• Recommended Tracking Force: 3.0 g (30 mN)
• Tracking Angle: 20°
• Internal Impedance, DC Resistance: 750 Ohm
• Cartridge Weight: 18.5 g
• Recommended Load Resistance: 47 kOhm
• Internal Inductance: 450 mH
• Recommended Load Capacitance: 200–600 pF
• Primary Applications: Scratching and mixing
• DJ Techniques: Scratching and back-cueing
