High Tracking Performance: The VNL delivers 90 µm tracking ability at 315 Hz when using the recommended 4 g tracking force. This helps maintain stable groove contact during demanding DJ techniques, including scratching, back-cueing, and intensive vinyl performance.

Spherical Diamond Stylus: The spherical diamond stylus features an R 18 µm tip radius, providing a design suited to demanding DJ use. Its profile supports reliable groove handling while helping minimise record wear during scratching and back-cueing.

Pre-Mounted VNL II Stylus: The cartridge includes the VNL II stylus pre-mounted on the cartridge body. Its 15 µm/mN dynamic lateral compliance provides the rigid suspension characteristic associated with the VNL II configuration.

Interchangeable Stylus Options: The VNL cartridge accepts three VNL stylus options with different suspension characteristics. VNL I offers a flexible feel, VNL II provides a rigid feel, and VNL III delivers a firm feel.

DVS and Vinyl Compatibility: The VNL supports high tracking performance for both DVS and traditional vinyl setups. Its cartridge body also facilitates mounting and alignment across compatible headshell configurations.

Ultrasonic and Robotic Construction: Ortofon uses ultrasonic welding to strengthen component uniformity and rigidity while reducing unwanted resonances. Robotic assembly of the stylus unit also supports consistent manufacturing precision.

Specifications:

• Brand: Ortofon
• Product: VNL All Round DJ Cartridge
• Cartridge Type: Moving Magnet
• Output Voltage at 1 kHz, 5 cm/sec: 6 mV
• Tracking Ability at 315 Hz: 90 µm
• Cantilever Material: Aluminium
• Stylus Type: Spherical Diamond
• Stylus Tip Radius: R 18 µm
• Pre-Mounted Stylus: VNL II
• Channel Separation at 1 kHz: 20 dB
• Frequency Response: 20 Hz – 20 kHz, –2 / +4 dB
• Dynamic Lateral Compliance: 15 µm/mN
• Recommended Tracking Force: 4 g
• Tracking Force Range: 3–5 g
• Recommended Load Resistance: 47 kOhm
• Cartridge Weight: 6.5 g
• Premounted Cartridge Weight: 16.0 g
• Cartridge Colour: White
• Internal Impedance / DC Resistance: 700 Ohm
• Internal Inductance: 450 mH
• Replacement Stylus: Stylus VNL
• Compatible Stylus Options: VNL I, VNL II, VNL III
• Recommended Load Capacitance: 200–600 pF
