High 10 mV Output: The VNL TRIX produces a powerful 10 mV output at 1 kHz and 5 cm/sec, delivering strong signal levels for demanding DJ systems. This high-output design provides the raw volume and energetic response needed for club environments, live stages, and performance-focused turntable setups.

Rock-Solid Tracking: With 100 μm tracking ability at 315 Hz, the VNL TRIX maintains secure groove contact during intensive DJ techniques. The cartridge handles scratching and back-cueing with stability, helping DJs maintain controlled playback when performance movements become particularly aggressive.

Spherical Diamond Stylus: The spherical diamond stylus provides a robust profile designed specifically for demanding DJ performance techniques. Combined with the 18 μm stylus tip radius, the design supports reliable groove tracking while remaining suited to scratching and back-cueing applications.

Fluorescent White Stylus: The fluorescent white stylus provides enhanced visibility under ultraviolet lighting, making the stylus easier to identify during dark booths and busy stages. Consequently, DJs can locate their stylus faster while performing cueing, beatmatching, scratching, and quick back-cue techniques.

Durable Aluminium Cantilever: The rigid aluminium cantilever gives the VNL TRIX a strong foundation for intensive turntable performance and demanding DJ techniques. Furthermore, Ortofon’s exclusive stylus suspension works with the cantilever to provide controlled tracking and dependable performance during challenging sessions.

Fully Interchangeable VNL Design: The VNL TRIX works with the wider VNL cartridge family, giving DJs greater flexibility when selecting compatible replacement styli. Therefore, users can change their stylus according to their preferred performance style while retaining the convenience of the VNL platform.

Specifications:

• Brand: Ortofon
• Product: VNL TRIX High Output DJ Cartridge
• Output Voltage at 1 kHz, 5 cm/sec: 10 mV
• Channel Separation at 1 kHz: 22 dB
• Frequency Response: 20 Hz – 20 kHz, ±3 dB
• Tracking Ability at 315 Hz: 100 μm
• Dynamic Lateral Compliance: 12 μm/mN
• Cantilever Material: Aluminium
• Stylus Type: Spherical diamond
• Stylus Tip Radius: R 18 μm
• Stylus Suspension: Ortofon exclusive
• Coil System: Quad coils
• Coil Wire Material: OFC
• Recommended Tracking Force: 4.0 grams
• Cartridge Colour: Black
• Cartridge Weight: 7 grams
• Stylus Colour: White
• Replacement Stylus: Stylus VNL TRIX
• Optimised For: Scratching and high tracking performance
• Mounting Type: Half-inch mount
