Low-Profile Design: The Sonance PS-C63RTLP is specifically engineered with a shallow 4.37” depth, making it perfect for installations where space is limited. It can be placed beneath HVAC ducting or in tight ceiling spaces without compromising on sound quality. This design ensures versatility for various residential and commercial installations.

High-Excursion 6.5″ Woofer: Equipped with a high-excursion 6.5″ polypropylene woofer, the PS-C63RTLP delivers rich bass performance, even at high volumes. The woofer’s advanced construction ensures deep bass extension and clear audio reproduction, making it ideal for environments where high-fidelity sound is essential.

Pivoting Chambered Tweeter: The 1″ soft dome, pivoting tweeter allows precise directional sound control. This feature ensures optimal coverage by allowing adjustments based on installation angle or room layout. Whether the speaker is mounted in challenging or irregular locations, it can still provide balanced and accurate sound.

Full-Fidelity Transformer: The PS-C63RTLP includes a full-fidelity transformer that supports 60W, 30W, and 15W (7.5W 70V) power configurations. This flexibility allows the speaker to perform efficiently in both low-impedance (8 Ohms) and high-impedance (70V, 100V) systems, making it adaptable for different audio setups in commercial or residential spaces.

Easy Installation with Bezel-less Grille: The speaker features a one-piece, bezel-less magnetic grille that not only simplifies installation but also delivers a sleek, modern aesthetic. The grille attaches easily, reducing installation time and ensuring a seamless look that blends with any ceiling design.

UL Certifications for Safety: With UL 1480 and UL 2043 certifications, the Sonance PS-C63RTLP guarantees performance and safety compliance in professional installations. These certifications provide peace of mind, ensuring the speaker meets rigorous industry standards for both residential and commercial applications.

Wide Coverage and High SPL: With a 120-degree nominal coverage angle and a maximum SPL of 116dB peak at 1 meter, the PS-C63RTLP ensures uniform sound distribution even in larger spaces. Its wide coverage makes it ideal for filling rooms with balanced audio, delivering exceptional sound clarity across the listening area.

Specifications:

• Woofer Size: 6.5” (165mm) polypropylene cone, butyl rubber surround
• Tweeter: 1” (25mm) cloth dome, pivoting, ferrofluid cooled
• Frequency Range:
  • (-10dB): 49Hz – 25kHz
  • (-3dB): 65Hz – 20kHz
• Power Handling:
  • Continuous Program Power: 120W
  • Continuous Pink Noise Power: 60W
• Nominal Sensitivity: 91dB
• Nominal Impedance: 8 Ohms (minimum 6 Ohms)
• Maximum SPL: 108dB average, 116dB peak at 1 meter (3.3 feet)
• Nominal Coverage Angle: 120° conical
• Transformer Taps:
  • 60W, 30W, 15W (7.5W 70V)
• Crossover Point: 2750Hz
• Dimensions:
  • Overall: 11.06” Diameter x 4.37” Depth (281mm x 111mm)
  • Cutout: 10.125” Diameter (257mm)
• Weight:
  • Net: 10 lbs (4.53kg)
  • Shipping: 38 lbs (17.23kg) per pair
• Grille: Bezel-less white grille (optional black grille or square adapter available)
• Input Connector: Four-pin Euroblock with loop output connections
• Knockouts: One back-mounted, one side-mounted 0.75” (19mm)
• Safety Certifications: UL 1480, UL 2043, NFPA 90A, NFPA 70
• Maximum Ceiling Thickness: 1.732” (44mm)
• Suspension Points: One on top surface
• Included Accessories: Bracket and Tile Bridge
