Audio Solutions
Showing all 9 results
-
Audio Solutions
DM8500
- Networked open architecture digital audio processor
- 64 x 64 channel, dual-redundant Dante*/AES67 audio transport
- 10 high-headroom analogue mic/line inputs
- 6 electronically balanced, low impedance line level outputs
- 24 channels of freely assignable Acoustic Echo Cancellation
- 16 channel ULTRANET audio output bus
- Class-compliant USB connection for integration with soft codec conferencing applications
- System configuration and control via ethernet
- Embedded HTML engine to serve custom control pages
- Integrated control modules for Lab Gruppen D series and Lucia amplifiers
- Embedded media engine for audio playback and recording
- RS232 connector for interfacing with 3rd party control systems
- 6 user-configurable general purpose input output connections (GPIO)
- Auto-ranging universal power supply
- Designed and engineered in the United Kingdom
SKU: n/a -
Audio Solutions
DN30R
- 2-Channel audio receiver for connecting active loudspeakers, amplifiers or mixers to Dante*-networks
- Automatically reconnects with any configured Dante transmitter such as Klark Teknik DN 30T
- Plug’n’play experience in networked audio
- Perfect for hospitality and event spaces, performance and installed audio, etc.
- 96 kHz D/A conversion and high headroom design offers superior sound quality
- Built-in headphone amplifier for local monitoring
- Aluminium extrusion casing with protective rubber corners
- Floor and wall mount brackets for fixed installation (included)
- Quality Neutrik* XLR connectors for highest reliability
- Compact and rugged design
- Designed and engineered in the U.K.
SKU: n/a -
Audio Solutions
DN30T
- 2-Channel audio transmitter for connecting mic/instrument and line level sources to Dante*-networks
- Automatically reconnects with any configured Dante receiver such as Klark Teknik DN 30R
- Plug’n’play experience in networked audio
- Perfect for hospitality and event spaces, performance and installed audio, etc.
- 96 kHz A/D conversion and high headroom design offers superior sound quality
- Aluminium extrusion casing with protective rubber corners
- Floor and wall mount brackets for fixed installation (included)
- Quality connectors for reliability
- Compact and rugged design
- Designed and engineered in the U.K.
SKU: n/a -
Audio Solutions
DN9630
- AES50 to USB 2.0 converter for simultaneous computer audio recording and playback
- Up to 48 bidirectional channels @ 48 kHz and 24 bidirectional channels @ 96 kHz
- Switchable 48 kHz and 96 kHz sample rate operation
- Operates from incoming AES50 clock
- Powered via USB 2.0 interface
- Native Core Audio* driver support in Mac OS X*, software drivers available for Windows* PC
- LED indicators monitor network activity and speed
- Compact and rugged design with durable aluminium extrusion casing
- Designed and engineered in the U.K.
SKU: n/a -
Audio Solutions, Audio Technology
DP48
- Dual 48 channel personal monitor mixer compatible with Midas personal monitoring system hubs
- 12 stereo groups enable rapid creation and balancing of personal mixes from fully configurable stem groups
- Dual mix feature allows independent control of two complete monitor mixes
- Integrated SD card interface for stereo recording and playback of rehearsal sessions and performances
- Built-in stereo ambience microphone provides on-stage sound feed to remove sense of isolation with in-ear monitors
- Studio-quality reverb adds spatial ambience to personal in-ear mixes, independent from main console
- Remotely powered via direct AES50 connection from Midas hubs featuring Power over Ethernet (PoE)
- Separate DC power supply allows daisy-chaining of DP48 personal monitor mixers and use without any PoE hub
- Compatible with any 44.1/48 kHz AES50-equipped devices including Midas and Behringer digital consoles and I/O boxes
- Midas PRO SERIES and M32 console input channel labelling and colour information transmitted to DP48 personal monitor mixer via AES50 input channels
- AES50 return channels allow personal mixes to be sent back to the console or hub for connection to wireless IEM transmitters
- Remote operation up to 100 m via screened CAT5/5e cable
- Remote setup and control of DP48 personal monitor mixer via Midas hubs
- Full remote control of another DP48 when both connected to the same hub or used in daisy chain configuration
- High-contrast 2.4″ colour TFT display screen provides clear overview of mix parameters, meters and group assignments
- Analogue stereo auxiliary input for local click track
- High power headphone output for use in all stage monitoring environments
- Fully adjustable limiter allows for safe monitoring levels within sound exposure limits
- Mounts securely on microphone stand with DP48MB adaptor (not included)
- Designed and engineered in the U.K.
SKU: n/a -
Audio Solutions
HUB4
- Personal monitoring system hub with PoE remote powering for up to 4 DP48 personal mixers and compatible stage boxes
- AES50 IN and THRU ports for cascading hubs or stage boxes with 48 bidirectional channels at 48/44.1 kHz
- 16 balanced analogue outputs for sending 4×2 personal stereo mixes to IEM transmitters in the side rack
- Channel naming and Group assignments can be distributed from compatible M32 consoles
- Midas DL8 Stage Boxes can be connected and powered from ports 1-4
- Personal mix outputs can be monitored via AES50 upstream to connected consoles
- Supports remote control forwarding of a DP48 personal mixer from another DP48
- Front panel buttons for sending signals to analogue output groups 1-4, for StageCONNECT and for AES50-A upstream
- StageCONNECT output with phantom power for connecting other StageCONNECT devices, sharing 32-channel audio, 24-Bit uncompressed PCM, 44.1/48 kHz, at sub-milisecond latency, over any standard XLR microphone or DMX cable
- Remote operation via shielded CAT5e cable up to 260 ft / 80 m length recommended
- Features Neutrik etherCON* AES50 network ports
- Rugged 1U chassis for durability in portable applications
- Auto-ranging universal switch-mode power supply
- Designed and engineered in the U.K.
SKU: n/a -
-
Audio Solutions
UCA222
- Ultra-flexible audio interface connects your instruments, mixer, etc. with your computer for recording and playback
- Massive software bundle including Audacity audio editor, comprehensive podcasting software and over 150 virtual instruments and effect plug-ins downloadable at www.behringer.com
- Works with your PC or Mac* computer—no setup or drivers required
- High-resolution 48 kHz converters for high-end audio quality
- Stereo Headphone output with dedicated Level control lets you monitor both input and output
- Additional S/PDIF optical output for direct digital conversion
- Powered via USB—no external power supply needed
- Designed and engineered in Germany
SKU: n/a -
Audio Solutions
UMC202HD
- 2×2 USB 2.0 audio interface for recording microphones and instruments
- Audiophile 24-Bit/192 kHz resolution for professional audio quality
- Compatible with popular recording software including Avid Pro Tools*, Ableton Live*, Steinberg Cubase*, etc.
- Streams 2 inputs / 2 outputs with ultra-low latency to your computer, supporting Mac* OS X* and Windows XP* or higher
- 2 state-of-the-art, Midas designed Mic Preamplifiers with +48 V phantom power
- Zero-latency direct monitoring while recording
- Powerful Phones output with Level control and Direct Monitor select
- Status, Signal and Clip indications for perfect overview
- USB port for connection and power
- Free audio recording, editing and podcasting software plus 150 instrument/effect plug-ins downloadable at behringer.com
- “Built-like-a-tank”, impact-resistant metal chassis
- Designed and engineered in Germany
SKU: n/a
