Nude Microlinear Stylus: Tracks record grooves with exceptional accuracy, reproducing subtle details and dynamic nuances that elliptical or conical styli cannot achieve.

Paratoroidal Coil Construction: Dual coils per channel increase generating efficiency, improving channel separation, balance, and transient response for precise stereo imaging.

PCUHD Copper Coils: Pure Copper Ultra High Drawability wire provides richer, more nuanced sound and faster transient response, enhancing musical clarity.

Center Shield Plate: Separates left and right channels to reduce crosstalk, maintaining a clean and defined stereo image across all frequencies.

Die-Cast Aluminum Body: Minimizes vibrations and resonance, improving overall sound clarity while providing a robust and durable cartridge housing.

Threaded Mounting Inserts: Simplifies installation on integrated tonearms and standard 1/2″ headshells, requiring only two screws for secure attachment.

V-Cut Stylus Protector: Provides a visual guide for lowering the stylus onto the record, protecting your stylus and improving placement accuracy.

Aluminum Tapered Cantilever: Reduces mass near the stylus tip for faster signal transmission, improving transient response and overall audio fidelity.

Compatibility: Works with most AT‑VMx series replacement styli, offering flexibility to experiment with different stylus types and sound characteristics.

Enhanced Sound Performance: Delivers clear highs, detailed mids, and tight bass, producing a wide, immersive soundstage for lifelike music reproduction.

Specifications:

• Type: VM dual moving magnet cartridge

• Stylus Construction: Nude Microlinear

• Stylus Curvature Radius: 2.2 × 0.12 mil

• Frequency Response: 20–25,000 Hz

• Channel Separation: 25 dB (1 kHz)

• Tracking Force: 1.8–2.2 g (2.0 g standard)

• Vertical Tracking Angle: 20°

• Output Voltage: 3.2 mV (1 kHz, 5 cm/sec)

• Output Balance: 1.0 dB (1 kHz)

• Recommended Load Impedance: 47 kΩ

• Coil Impedance: 3.2 kΩ (1 kHz)

• DC Resistance: 750 Ω

• Coil Inductance: 480 mH (1 kHz)

• Static Compliance: 20 × 10⁻⁶ cm/dyne

• Dynamic Compliance: 7 × 10⁻⁶ cm/dyne (100 Hz)

• Cantilever: Aluminum tapered pipe

• Dimensions: 29 × 18.3 × 17.5 mm (H × W × D)

• Weight: 8.8 g

• Accessories: Installation screws, washers, non-magnetic screwdriver, brush

• Replacement Stylus: AT-VMN40xML (sold separately)
