High-Quality Sound Performance

The dB Technologies KL10 features a 10” woofer and a 1” compression driver with a 1” voice coil, delivering clear, detailed sound. A powerful 400W amplifier drives the system, paired with advanced DSP processing. Linear phase FIR filters ensure consistent, uniform audio across all listening positions.

Advanced DSP Presets

The KL10 includes DSP presets such as Playback, Flat, Bass Boost, and Wedge, allowing users to optimize the sound output based on their environment. This feature enables sound enhancement for both low and high frequencies, providing full control over audio characteristics.

Flexible Input and Output Options

This speaker offers three input channels, including a balanced combo XLR/6.3mm jack for mic/line inputs, an XLR/TRS jack input, and Bluetooth® connectivity for wireless devices. The XLR-M output enables easy linking to another speaker or mixer, providing flexibility for various setups.

Portable and Versatile Design

With a solid polypropylene housing, the KL10 is built for durability. The speaker has three integrated handles for easy transportation and can be used as a stage monitor with a 40° upward tilt. Additionally, the pole mount features two tilt angle options (0° and 7.5°), making the speaker adaptable for different configurations.

Durable Protection and Easy Transport

The KL10 comes with a soft cover that provides protection during storage and transportation. The cover also includes a pocket for cable storage, ensuring that all components remain organized and safe.

Specifications:

• Speaker Type: 2-Way Active Speaker
• Frequency Response [-10dB]: 55 – 18.000 Hz
• Max SPL: 125 dB
• HF: 1″ CD, 1″ v.c.
• LF: 10″, 2″ v.c.
• Dispersion: 90° x 60°
• Crossover Frequency: 2000 Hz (24 dB/oct.)
• Amp Technology: Class D (LF) + Class AB (HF)
• Power Peak (LF+HF): 400 W
• Controls: 1x Volume, 1x slide switch mic/line
• Indicators: Power on/signal/limiter LEDs
• Controller: DSP 20/56 bit
• AD/DA Converter: 24 bit / 48 Hz
• Input Signal: 1x Combo (XLR/Jack) Mic/Line, 1x XLR/TRS, Bluetooth Input
• Signal Out: 1x XLR Male (LINK/MIX)
• Housing: Polypropylene
• Handles: 3 (2 on side, 1 on top)
• Angles Up: Monitor Use 40°
• Pole Mount: 36 mm, double positioning
• Width: 310 mm (12.2 in)
• Height: 521 mm (20
