Powerful Audio Performance: The KL12 boasts an impressive 800W peak power output, driven by a Class D amplifier for the low frequencies and a Class AB amplifier for the high frequencies. It delivers crisp, clear sound across a wide frequency range of 52 Hz to 18,000 Hz, ensuring accurate audio reproduction in diverse settings.

Advanced DSP Processing: The integrated DSP processor features linear phase FIR filters, which enhance the accuracy and coherence of the sound. This helps to maintain clarity across all frequencies and prevents distortion. The DSP also includes several system presets, including playback, flat, bass boost, and wedge modes, offering flexibility for various audio applications.

Bluetooth Connectivity: The KL12 includes Bluetooth® capability, allowing for seamless wireless audio streaming from compatible devices. This feature simplifies setup and offers more flexibility, especially in environments where cables are impractical or unwanted.

Multiple Input Channels: Equipped with three input channels, the KL12 provides flexibility for connecting multiple audio sources. It features a balanced combo XLR/6.3 mm Jack input, a balanced XLR/TRS input, and a Bluetooth® input for wireless streaming, allowing users to connect a wide variety of devices.

Portability and Durability: The speaker is housed in a lightweight, durable polypropylene enclosure that ensures it can withstand regular use in demanding environments. It includes three integrated handles for easy transport and setup. Additionally, the KL12 can be used both as a standard speaker and a floor monitor, offering versatility in positioning.

Pole Mount and Monitor Use: The KL12 features a pole mount for easy integration with tripods or stacked with dB Technologies subs. It also has a 45° angle for optimal sound projection when used horizontally as a stage monitor. This flexibility makes the KL12 suitable for a wide range of performance scenarios.

Limiter Protection: To ensure safe operation, the KL12 comes with built-in protection from distortion and overheating. The limiter functions prevent damage to the speaker by regulating peak levels and thermal overload.

Specifications:

• Speaker Type: 2-Way Active Speaker
• Frequency Response (-10dB): 52 Hz – 18,000 Hz
• Maximum SPL: 127 dB
• High-Frequency Driver: 1″ Compression Driver with 1.35″ Voice Coil
• Low-Frequency Driver: 12″ Woofer with 2.5″ Voice Coil
• Dispersion: 90° x 60°
• Crossover Frequency: 1,800 Hz (24 dB/octave)
• Amplifier Technology: Class D (LF) + Class AB (HF)
• Peak Power: 800 W (LF + HF)
• Processor: DSP with 20/56-bit processing
• Input Channels: 3 (Combo XLR/Jack, XLR/TRS, Bluetooth)
• Output: 1 x XLR Male (Link/Mix)
• Housing: Polypropylene with integrated handles
• Monitor Angle: 45°
• Pole Mount: 36 mm with double positioning
• Dimensions (W x H x D): 365 mm x 622 mm x 342 mm
• Weight: 16.5 kg
