Power Supply Flexibility: The Powersoft X8 DSP+ETH Amplifier is designed for maximum flexibility in power supply. It supports Single Phase, Bi-Phase, and Three Phase operation, with a wide input voltage range from 85 VAC to 460 VAC. This feature ensures compatibility with global power systems without manual selection, making it easier to deploy in various locations.

True Three Phase Load Balancing: One of the standout features of the Powersoft X8 is its True Three Phase load balancing. This allows for an even distribution of power across all phases, which simplifies setup and eliminates the need for complex load assignments. This feature ensures greater efficiency and reliability in multi-phase systems.

Eight Fully Processable Channels: The amplifier provides eight fully processable channels, which can handle a range of inputs, from analog sources to digital AES3 and two redundant Dante™ streams. This versatility in input options gives users the flexibility to integrate the X8 into a wide variety of audio setups.

Low-Latency DSP Integration: The integrated low-latency DSP provides powerful signal processing capabilities, enabling precise channel mixing, routing, and sound shaping. This DSP ensures minimal delay and high-quality audio, giving users complete control over their sound systems, from initial signal processing to final output.

Advanced Sound Shaping and Speaker Management: The X8’s DSP allows for extensive sound shaping and speaker management. Users can easily configure, route, and mix channels, ensuring optimal sound performance in any environment. This makes the Powersoft X8 ideal for both touring and permanent installations where high-quality audio control is essential.

Remote Control and Monitoring: The Powersoft X8 includes Ethernet connectivity, allowing for remote control and monitoring via the DSP+ETH feature. This enables users to adjust settings, monitor performance, and troubleshoot remotely, ensuring smooth operation during live events or installations.

Built-in Redundancy: For enhanced reliability, the Powersoft X8 includes built-in redundancy through its dual Dante™ inputs. This feature ensures continuous operation even if one input fails, providing extra security in demanding applications.

Specifications:

• Number of Channels: 8​

• Output Power per Channel:

  • 2 Ω: 5,200 W​

  • 4 Ω: 3,000 W​

  • 8 Ω: 1,600 W​

• Bridge Mode Output:

  • 4 Ω: 10,400 W​

  • 8 Ω: 6,000 W​

• Maximum Output Voltage/Current: 175 Vpeak / 130 Apeak​

• Power Supply: Universal (Single Phase, Bi-Phase, or Three Phase), 85 V – 440 V​

• DSP Architecture: ARM Cortex A-8 processor with TI C6000 DSP platform​

• Input Equalizer: Raised-cosine, custom FIR, parametric IIR​

• Output Equalizer: Raised-cosine, custom FIR, parametric IIR​

• Crossover: Linear phase (FIR), hybrid (FIR-IIR), Butterworth, Linkwitz-Riley, Bessel

• Delays:

  • Input: Up to 4 s​

  • Output: Up to 200 ms​

• Limiters: TruePower™, RMS voltage, RMS current, Peak limiter​

• Damping Control: Active DampingControl™​

• Dimensions (L x H x W): 483 x 88 x 495 mm

• Weight: 24 kg​
