High-Performance Drivers: The iQ10 features a 10-inch low-frequency driver with a low-mass voice coil, delivering quick and accurate transient response. Additionally, its high-temperature 1-inch compression driver, equipped with a copper-clad aluminum voice coil, ensures clear and extended high-frequency reproduction.

Powerful Amplification: Powered by an efficient Klark Teknik Class-D amplifier, the iQ10 offers an impressive 2,500 watts of output power. This allows for dynamic sound reinforcement suitable for both music and speech applications, ensuring clarity and punch even at high volumes.

Advanced DSP Technology: The integrated Klark Teknik Digital Signal Processor (DSP) provides comprehensive system control. It features dynamic EQ and transparent limiting, allowing for consistent sound quality across various volume levels. Users can easily manage performance with intuitive controls, optimizing audio output for different environments.

Speaker Modeling Presets: The iQ10 includes advanced speaker modeling presets that emulate industry-standard speakers. This feature enhances versatility, allowing users to shape their sound to meet specific needs or preferences, making it a valuable tool for sound professionals.

Spatial Contour Control (SCC): The Spatial Contour Control (SCC) optimizes the speaker’s frequency response based on its placement. Whether the speaker is on the floor, mounted on a wall, or placed on a stand, SCC adjusts the audio output to compensate for the acoustic environment, enhancing overall sound quality.

User-Friendly Interface: The rear panel features a fully equipped user interface, including an LCD display, rotary encoder, and gain controls. This setup allows for easy navigation and access to essential settings such as EQ, speaker modeling, SCC, and feedback control.

ULTRANET Digital Audio Networking: The iQ10 supports Turbosound’s ULTRANET technology, enabling seamless digital audio networking with other ULTRANET-enabled devices. Using CAT5 cables, this system reduces setup time and eliminates interference commonly found in analog connections.

Durable Construction: Designed for longevity and reliability, the iQ10 features a lightweight, fiberglass-reinforced composite enclosure and a rugged, powder-coated perforated steel grille. This robust construction ensures the speaker can withstand the rigors of both portable and permanent installations.

Versatile Mounting Options: The iQ10 includes a dual-angle pole mount socket, allowing for precise positioning to ensure optimal audience coverage. Additionally, multiple internal rigging points facilitate various installation configurations, making it adaptable for a range of settings.

Specifications:

• System Type: 2-way active loudspeaker
• Frequency Response:
  • 55 Hz – 18 kHz ±3 dB
  • 50 Hz – 20 kHz -10 dB
• Nominal Dispersion: 90° H x 60° V @ -6 dB points
• Maximum SPL: 129 dB peak
• Crossover Type: Active
• Transducers:
  • 1 x 10″ (256 mm) low-frequency driver
  • 1 x 1″ (25.4 mm) high-frequency compression driver
• Limiter: Independent HF, LF, peak, and RMS

Amplifier:

• Maximum Output Power: 2,500 W
• Type: Class-D
• Protection: Short circuit, open circuit, thermal

Connectors:

• Input A / B: 2 x combo jack/XLR
• Sensitivity: Line +4 dBu, mic -22 dBu, switchable
• Input Impedance: 20 kΩ unbalanced, 40 kΩ balanced
• Maximum Input Level: +21 dBu
• Output A / B: 2 x XLR linked to input
• Mix Output: XLR, balanced
• Output Impedance: 100 Ω unbalanced, 200 Ω balanced
• ULTRANET Input/Link: 2 x RJ45
• Mains Supply: Neutrik powerCON input 20A and link 15A

Controls:

• DSP: Rotary push-encoder
• Buttons for DSP Functions: PROCESS, SETUP, EXIT, ENTER
• Mixer Section: 2 x gain controls (channels A and B), 2 x Line/Mic switch

User DSP Functions:

• Factory EQ Presets: Positioning, Sound mode, Sound modeling, FBQ
• Display: LCD 128 x 32, blue backlit
• Delay: 0 – 300 ms
• Equalization: High and low shelving EQ, 2 x parametric EQ
• Limiter: Zero attack input limiter
• Presets: 20 total presets, 19 user-definable
• Crossover: High Pass L-R 24 dB/oct
• Protection: Lock-out function for all settings

Enclosure:

• Dimensions (HWD): 526 x 324 x 316 mm (20.7 x 12.7 x 12.4 inches)
• Net Weight: 17.2 kg (38 lbs)
• Construction: Injection-moulded polypropylene enclosure
• Finish: Black painted
• Grille: Powder-coated perforated steel
• Flying Hardware: M10 x 3 points

Power Consumption:

• Power Consumption: 150 W @ 1/8 max power
• Voltage (Fuses): Standard power input
